- Battery pack
- N-Series
NH2054QE34
14.4V 6.8Ah high-capacity smart pack, 8A discharge, low-temperature capable.
- Voltage
- 14.4 V
- Capacity
- 6.8 Ah
- Energy
- 98 Wh
- Current
- 8 A
Specifications
| Nominal voltage | 14.4 V |
|---|---|
| Capacity | 6.8 Ah |
| Energy | 98 Wh |
| Maximum discharge current | 8 A |
| Rated power | 80 W |
| Chemistry | Lithium-ion |
| Cell | 8 x 18650 |
| Cell array | 4S2P |
| Shape | Rectangular |
| Dimensions (in) | 6" x 3.1" x 0.9" |
| Dimensions (mm) | 153 x 78.7 x 23 |
| Equivalent lithium content | 8 g |
| Communications | SMBUS |
| Fuel gauge | Always on 5-Bar LCD |
| IP rating | None |
| Mating connector | AMP P/N 5787422-1 or 5787446-1 |
| Cavity size | 23.5mm x 80mm cross section |
| Optional belt pack | MPL205X or MCL205X |
Approvals
- IEC
- UL
- BIS
- KC
- PSE
Chargers for this pack
Documents
That address never changes. The revision is a field, not part of the filename, so issuing revision 1.7000000000000002 replaces the file behind the same URL. Today the version is in the filename, so every revision 404s the previous link.
Typical applications
- Medical
- Military
- Aerospace
- Robotics
About this part
The high-capacity member of the 2054 family. Doubles the parallel string for roughly twice the runtime at twice the continuous current, in the same cavity cross-section as the ND2054, so it drops into an existing design as a straight upgrade.
